Pushbutton Transmitter THS-51

The Allrounder

The pushbutton transmitter THS-51 with its shock-resistant housing is equipped with all necessary features to meet the most of customer requirements. It is available as a replacement for the FW25 Series as THS-21, FW30 Series as THS-31 and FW40 Series as THS-41. Each transmitter is provided with a key lockable switch for protection against unauthorized operation and an emergency stop switch to transmit an active emergency stop via radio. Optionally, an IR transmitter for the infrared release is included, the radio transmitter is optionally available with the edge protection KTS-THS51. Power is supplied from a change-over battery AK5 to the transmitter without memory effect, based on proven NiMH technology, providing a continuous operation time of up to 18 hours.

Make a request

LED indication for transmitter status
OLED display for additional system information
Optional feedback data can be indicated specifically on the OLED display
Internal diagnosis interfaces for the service
Optional with built-in infrared transmitter to release the existing radio connection
Optional Windows based diagnosis software for parameter adjustment and inspection
Can be used as a switchable replacement transmitter for up to 11 different transmitters

Technical data

Type	THS-51
Pushbutton	up to 12 (up to 10 two-step)
Joysticks	none
Batterie type	changeover battery AK5
Operational hours	up to 18 hours under continuous operation
Energy saving mode	yes (adjustable)
Infrared release (optional)	yes
Feedback (optional)	yes, with integrated display
Frequency range	433.075 to 434.750 MHz / 869.725 to 869.975 MHz / 2,4 GHz
Operating range	up to 300 m / up to 200 m
Transmitting power	≤ 10 mW / ≤ 100 mW
Protection class / operating temp.	IP65 / -20 to +60 °C
Dimensions (W x H x D)	84,5 x 242 x 53 mm
Weight	470 g (incl. change-over battery)
